| Specification | |
|---|---|
| Technical Property | Specification Value |
| Model | CA-12Sub |
| Type | 1x12" Active Subwoofer |
| Transducers | 1x12" (300mm) Ferrite Unit |
| Frequency Response (Hz) | 38Hz – 200kHz |
| Sensitivity (1W/1m) | 97dB |
| Max SPL | 128dB |
| Rated Power | 400W |
| Nominal Impedance | 8Ω |
| Connection | 1x Speakon connector |
| Dimensions (W x H x D) | 409 x 590 x 469 mm |
| Weight (kg) | 28.5 |
| Amplifier Module | |
| Power | 400W + 1200W @ 8Ω, 600W + 2000W @ 4Ω |
| RMS Output Voltage | 100V 8Ω |
| THD+N (at 10% rated power) | < 0.6% |
| IMD-SMPTE (at 10% rated power) | < 0.9% |
| Crosstalk | 65dB |
| Frequency Response (Hz) | 20Hz – 20kHz |
| Signal-to-Noise Ratio (A) | > 90dB |
| AC Input | 110V-220V 50/60Hz |
| Operating Temperature | 0°C to + 40°C |
